ان وی آر 16 کانال یک و سه مگا ساپورت و یا هشت کانال دومگا مدل ADK-1016
- برند: ای دی کی
- کد: 4096371
Key Features
• P2P cloud service, including cloud connecting, cloud monitoring, cloud transmitting to access IPC and NVR
at any time and any place
• Support Onvif protocol, support High profile S, High profile G, compatible with different IP camera that based on Onvif, RTSP standard
• Support megapixel HD network video preview, storage and playback;
• Support search, playback and backup by event;
• Support all channel image display on one screen at same time, support 4 channels’ image display by ainstream,
and 4 channels playback;
• Support monitor PTZ on preview mode
• Offer CMS for free
Model Number |
ADK-1016 |
|
Operating System |
Embedded LINUX operating system |
|
Image Code Control |
Image code quality adjustable, variable bitstream and constant bitstream optional |
|
Dual Stream |
Each channel can set main stream and sub stream |
|
Video Standard |
1080P(1920×1080)30Frame/Sec./960P/(1280×960)/720P(1280×720)30Frame/Sec. |
|
Monitoring Image Quality |
1080P(1920×1080) / 960P/(1280×960)/720P(1280×720) |
|
Image Motion Detection |
Each screen can set mutiple detection areas and set 6-level sensitivity(IPC Support) |
|
Recording Playback Quality |
Any 4ch playback simultaneously |
|
Region Cover |
Every channel can set 4 cover regions(IPC Support) |
|
Recording Mode |
Support manual , auto, dynamic detection, alarm trigger record mode(Partly needs IPC Support) |
|
Backup Way |
Support U disk, USB mobile HDD, USB DVD-RW network storage and backup |
|
Operation Way |
Mouse |
|
Local Login |
User name and password |
|
Recording Storage |
Local HDD, network |
|
External Ports |
Video Input |
|
|
||
③ 4×(1920*1080)+sub[720*576]+2Ref.+1Play 4CH 2.0MP IP Camera |
||
④ 4×(1280*720)+sub[720*576]+2Ref.+4Play 4CH 1.0MP IP Camera |
||
Audio Input |
16ch network audio input |
|
Video Output |
1ch VGA+1ch HDMI (HDMI synchronization output audio) |
|
Network Port |
1 RJ45,10M/100M self-adaptive LAN port |
|
USB Port |
2 USB 2.0 ports |
|
Wireless Port |
WIFI |
|
HDD |
HDD Port |
1 SATA HDD Port |
MAX Capacity |
Each port supports MAX 6TB HDD |
|
Mobile Surveillance |
Support( iPhone, Windows Mobile, BlackBerry, Symbian, Android) smart phone |
|
Power Supply |
12V2A |
|
Power Consumption |
≤25(without HDD) |
|
Working Temperature |
-10℃~+55℃ |
|
Working Humidity |
10%-90% |
|
Dimension |
Equipment:260mm×220mm×43mm, Packing:355mm×255mm×88.5mm |
|
Weight(without HDD) |
N.W.:1.5Kg;With packing:2.4Kg |
|
Outside Carton |
10 pcs/carton. 525mm×455mm×365mm; Weight:25 Kg |
|
Installation Way |
Desktop Installation |
