ان وی آر 128 کاناله و 16 هارد 10 ترا بایتی جوویژن مدل JVS-ND92128-HV
Key Features
• 4K Video Output
• Adopt the new VStar GUI, easy to operate and run smoothly
• Support intelligent coding VSmart, greatly reducing storage space
• Improved compatibility for HDD. Support 16x SATA max. of 10TB
• Support Alarm-In and Alarm-Out. 16 Input and 4 Output.
• Support RS485
• Support Intelligent Detection and Human Detection
• Support dual Network Interface, Dual HDMI and Dual VGA
Specifications
| Model |
JVS-ND92128-HV |
| Video & Audio |
| IP Camera Input |
128 Channel |
| Audio Input/ Output |
1 Channel RCA Output, 1 Channel RCA Input128 Channel Audio output
through HDMI
|
| Display |
| Interface |
2 HDMI, 2 VGA |
| Video Output |
HDMI: 3840x2160/ 2560x1440/ 1920x1080/ 1440x900/ 1280x1024/ 1280x720/ 1024x768
|
| VGA: 1920x1080/ 1440x900/ 1280x1024/ 1280x720/ 1024x768 |
| Max Decoding |
128CH 5.0MP/ 4.0MP/ 1080p/ 960p/ 720p @25fps |
| Multi-Screen Display |
1/ 4/ 5/ 6 up to 64x2 |
| OSD |
Camera Name & Time, Recording, Alarm Detecting, Remote connection,
Volume, Channel Number
|
| Recording |
| Compression |
H.265/H.264 |
| Resolution |
128CH 5.0MP/ 4.0MP/ 1080p/ 960p/ 720p |
| Record Mode |
Manual, Schedule, Motion Detection |
| Video Detection & Alarm |
| Trigger Events |
Recording, Snapshot, PTZ, Voice, E-mail, Client, Buzzer |
| Video Detection |
Motion Detection, No Video Detection |
| Alarm-In & Out |
16CH Alarm Input; 4CH Alarm Output |
| Playback & Backup |
| Sync Playback |
9CH 5.0MP @20fps/ 11CH 4.0MP/ 13CH 3.0MP/16CH 1080p |
| Search Mode |
Channel Number / Recording Type / Date |
| Playback Function |
Day View, Hour View, Back Step, Rewind, Pause, Play, Fast Forward,
Slow, Step, Full Screen, Snap, Sound On/Off, Zoom
|
| Backup Mode |
FAT32/ NTFS/ exFAT USB Device / Network |
| Network & Interfaces |
| Network Interface |
2x RJ45 (10/100/1000Mbps) |
| Network Function |
TCP/IP, DHCP, UDP, SMTP, NTP, CloudSEE |
| Smart Phone |
Support iOS, Android App |
| Interoperability |
ONVIF 2.4 |
| PTZ Interface |
RS485 |
| Storage |
| SATA |
16 SATA Interface |
| Capacity |
Up to 10TB |
| USB |
2x USB2.0, 1x USB3.0 |
| General |
| Power Supply |
100~240V/ 6~3A/ 50~60HZ |
| Consumption |
≤10W (Without HDD) |
| Working Temperature |
-10°C ~ 55°C |
| Working Humidity |
10% ~ 90% |
| Dimensions |
530x144x483mm |
| Weight |
≤6.2Kg (Without HDD) |
