Key Features

• Motorized Varifocal Lens (2.7-13.5mm) for easy installation and monitoring

• Stainless steel 304, Corrosion Proof for marine area

• Human, Vehicle, and Pet Detection, Leave Detection, Road Occupation Detection based on AgiSense Technology

• IECE x, EN IEC 60079-0:2018, EN 60079-1:2014 and EN 60079-31:2014

• Enclosure Protection: IP68

• Specifications

  Video
  Image Sensor	1/3" CMOS
  Max Resolution	2560x1792
  Effective Pixels	5.0MP
  Compression Standard	H.264/H.265+
  Framerate	30fps
  Bitrate	Main Stream: 256Kbps ~ 4096Kbps Sub Stream: 68Kbps~1024Kbps Third Stream: 68Kbps~1028Kbps
  SNR (dB)	≥50dB
  Min. Illumination	0.0Lux (light ON)
  Lens
  Lens	Varifocal Lens, Motorized Lens, 2.7mm-13.5mm
  Focal lens & FOV	2.7mm-13.5mm     Horizonal FOV: 101.4° to 26.9° Vertical FOV: 53.6° to 15.2°           Diagonal FOV: 118.7° to 30.5°
  Function
  Exposure Control	Auto
  White Balance	Auto
  Gain Control	Auto
  Digital 3D Noise Reduction	Support
  OSD Information Setting	By default: The customized OSD supports a maximum of six lines, each line contains a maximum of 32 characters. One Chinese character is counted as two characters
  SNTP	Support
  Schedule Reboot	Support
  Smart Motion Detection	Support (Human, Vehicle, Pet)
  Image Setting	Support Saturation, Brightness, Contrast, Sharpness adjustment
  Image Style	Standard, Soft, Transparent
  Day and Night Function	Always Black & White
  Privacy Mask	Support up 8 areas
  Night Vision Optimization	Support
  WDR	120dB
  Screen Settings	Screen mirroring, Screen flipping
  IP Adaptation	Support automatic adaptation of IP address (Optional)
  Intelligent Analysis	Support Leave Detection, Road Occupation Detection
  Alarm Method	Email Alarm, Client Alarm
  Remote Operation	System, Video, Image, Alarm, Network management, Intelligent Analysis
  Network
  Ethernet	10/100Mbps Ethernet
  Stream	3x Streams
  Network Protocols	HTTP, TCP/IP, UDP, ICMP, RTSP, RTP, RTCP, SMTP, DHCP, DNS
  Access Protocol	Standard ONVIF, Public Cloud
  Network Transmission	CloudSEE 2.0
  Fusion Cloud Platform	Support
  Browser	IE8+, Chrome18+, Firefox5.0+, Safari5.02+
  User	Up to 13 Users
  App	Support iOS/Android
  General
  Lights	4 IR LEDs
  IR Distance	Up to 80 Meters
  Waterproof Level	IP68
  Power Supply	AC 220V
  Power Consumption	<7.5W
  Working Temperature	–40°c～+60°C
  Working Humidity	≤95%  （+25°c）
  Color/Material	Stainless steel 304, Corrosion-proof for marine area
  Dimensions (WxHxD)	165x160x270mm
  Weight	6.5Kg
  Installation Method	Wall
