ان وی آر 8 کاناله دارای 8 پورت شبکه پی او ای و یک پورت شبکه آپلینک برند جوویژن مدل JVS-ND7008-PD01
Key Features
• Adopt the new VStar GUI, easy to operate and run smoothly
• Support intelligent coding VSmart, greatly reducing storage space
• Improved compatibility for HDD. Support max. of 8TB
• Support Intelligent Detection and Human Detection
• Support 8 Channel IEEE802.3af PoE
Specifications
| Model |
JVS-ND7008-PD01 |
| Video and Audio |
| IP Camera Input |
8 Channel |
| Audio Input/ Output |
1 Channel RCA Output, 1 Channel RCA Input8 Channel Audio output through HDMI |
| Display |
| Interface |
1 HDMI, 1 VGA |
| Resolution |
HDMI: 3840x2160, 1920x1080, 2560x1440, 1440x900, 1280x1024, 1280x720, 1024x768
|
| VGA: 1920x1080, 1440x900, 1280x1024, 1280x720, 1024x768 |
| Max Decoding |
8CH 5.0MP/4.0MP/1080p/960p/720p @25fps |
| Multi-screen Display |
1/ 4/ 5/ 6/ 7/ 8/ 9 |
| OSD |
Camera Name & Time, Recording, Alarm Detecting, Remote connection,
Volume, Channel Number
|
| Recording |
| Compression |
H.265/H.264 |
| Resolution |
8CH 5.0MP/ 4.0MP/ 1080p/ 960p/ 720p |
| Record Mode |
Manual, Schedule, Motion Detection |
| Video Detection and Alarm |
| Trigger Events |
Recording, Snapshot, PTZ, Voice, E-mail, Client, Buzzer |
| Video Detection |
Motion Detection, No Video Detection |
| Playback & Backup |
| Sync Playback |
2CH 5.0MP/ 3CH 4.0MP/ 4CH 3.0MP |
| Search Mode |
Time /Date, Schedule, Motion Detection |
| Playback Function |
Day View, Hour View, Back Step, Rewind, Pause, Play, Fast Forward,
Slow, Step, Full Screen, Snap, Sound On/Off, Zoom
|
| Backup Mode |
FAT32 USB Device/ Network |
| Network & Interfaces |
| Interface |
1 RJ45 Port (10/100/1000Mbps) |
| PoE Interface |
8 Port 100Mbps IEEE802.3af PoE |
| Network Function |
TCP/IP, DHCP, UDP, SMTP, NTP, CloudSEE |
| Smart Phone |
Support iOS, Android App |
| Interoperability |
ONVIF 2.4 |
| Storage |
| SATA |
2x SATA interface |
| Capacity |
Up to 8TB |
| USB |
2x USB |
| General |
| Power Supply |
48V DC |
| Consumption |
≤15W (Without HDD) |
| Working Temperature |
-10°C ~ 55°C |
| Working Humidity |
10% ~ 90% |
| Dimensions |
360x264x45mm |
| Weight |
≤2Kg (Without HDD) |
